Heating Equipment
Product Parameter
Type | AREA | Size (mm) | Voltage (V) | Power (W) | Technology |
XT-FQTC-Φ250X255 | 1 area | Φ250X255 | 3X400 | 8000 | 1.The use en Vironment temperature -20 degree C to 60 degree 2.Leakage current less than 0.5mA 3.Insulation resistance more than 5M 4.withstand voltage: 1500V 5.wattage tolerance +5%-10% |
XT-FQTC-Φ200X220 | 2 area | Φ200X220 | 230 | 4100 | |
XT-FQTC-Φ200X175 | 3 area | Φ200X175 | 230 | 2400 | |
XT-FQTC-Φ152/Φ140X310 | 4 area | Φ152/Φ140X310 | 230 | 3600 | |
XT-FQTC-Φ305X295 | 1 area | Φ305X295 | 3X400 | 1000 | |
XT-FQTC-Φ245X260 | 2 area | Φ245X260 | 230 | 4130 | |
XT-FQTC-Φ245X215 | 3 area | Φ245X215 | 230 | 3540 | |
XT-FQTC-Φ165/Φ185X365 | 4 area | Φ165/Φ185X365 | 230 | 4600 | |
XT-FQTC-Φ217X190 | 1 area | Φ217X190 | 230 | 4000 | |
XT-FQTC-Φ170X380 | 2 area | Φ170X380 | 230 | 5200 | |
XT-FQTC-Φ123X220 | 3 area | Φ123X220 | 230 | 2600 | |
XT-FQTC-Φ375X345 | 1 area | Φ375X345 | 3X400 | 16000 | |
XT-FQTC-Φ295X315 | 2 area | Φ295X315 | 230 | 6350 | |
XT-FQTC-Φ295X255 | 3 area | Φ295X255 | 230 | 4940 | |
XT-FQTC-Φ215/Φ195X430 | 4 area | Φ215/Φ195X430 | 230 | 5930 | |
XT-FQTC-Φ350X360 | 1 area | Φ350X360 | 3X400 | 18000 | |
XT-FQTC-Φ350X120 | 2 area | Φ350X120 | 3X400 | 6500 | |
XT-FQTC-Φ310X350 | 3 area | Φ310X350 | 3X400 | 8600 | |
XT-FQTC-Φ280X300 | 4 area | Φ280X300 | 3X400 | 4600 | |
XT-FQTC-Φ250X290 | 5 area | Φ250X290 | 3X400 | 4200 | |
XT-FQTC-Φ250/Φ210X510 | 6 area | Φ250/Φ210X510 | 3X400 | 8600 | |
XT-FQTC-Φ75X162 | Φ75X162 | 230 | 1400 | ||
XT-FQTC-Φ90X220 | Φ90X220 | 230 | 1500 | ||
XT-FQTC-Φ130X280 | Φ130X280 | 230 | 2200 | ||
XT-FQTC-Φ140X325 | Φ140X325 | 230 | 4000 | ||
XT-FQTC-Φ150X420 | Φ150X420 | 400 | 5000 | ||
XT-FQTC-Φ175X460 | Φ175X460 | 400 | 7000 | ||
XT-FQTC-Φ200X550 | Φ200X550 | 400 | 12000 |
